Dimension of sliding table |
1500×310mm |
|
Gross cut capacity |
1500mm |
|
Width of cut between saw blade and rip fence |
900mm |
|
Saw blade diameter |
300mm(φ250-φ300) |
|
Height of cutφ300mm |
65mm |
|
Speed of main saw spindle |
4000/6000rpm |
|
Main spindle diameter |
30mm |
|
Tilting saw blade |
90° |
|
Main motor |
4KW |
|
Scoring saw blade diameter |
120mm |
|
Speed of scoring saw blade |
8000r/min |
|
Scoring spindle diameter |
20mm |
|
Scoring motor |
0.75kw |
|
Net weight |
480kg |
|
Gross weight(with wooden package) |
550kg |
|
Overall dimensions |
1600×2500×880mm |
