Dimension of sliding table |
1600×360mm |
|
Gross cut capacity |
1600mm |
|
Width of cut between saw blade and rip fence |
1250mm |
|
Saw blade diameter |
300mm(φ250-φ315) |
|
Height of cutφ300mm |
80mm |
| Height of cut with saw blade 300mm at 45 | 55mm |
|
Speed of main saw spindle |
4000/6000rpm |
|
Main spindle diameter |
30mm |
|
Tilting saw blade |
45° |
|
Main motor |
4KW |
|
Scoring saw blade diameter |
120mm |
|
Speed of scoring saw blade |
8000r/min |
|
Scoring spindle diameter |
20mm |
|
Scoring motor |
0.75kw |
|
Net weight |
483kg |
|
Gross weight(with wooden package) |
556kg |
|
Overall dimensions |
1700×2500×880mm |
