Dimension of sliding table |
3200×435mm |
|
Gross cut capacity |
3200mm |
|
Width of cut between saw blade and rip fence |
1250mm |
|
Saw blade diameter |
300mm(φ250-φ350) |
|
Height of cut |
80mm |
|
Diameter of guide shaft spindle |
∮50mm |
|
Speed of main saw spindle |
3000/4000/5000rpm |
|
Main spindle diameter |
30mm |
|
Tilting saw blade |
0-45° |
|
Main motor |
5.5KW |
|
Scoring saw blade diameter |
120mm |
|
Speed of scoring saw blade |
8000r/min |
|
Scoring spindle diameter |
20mm |
|
Scoring motor |
0.75kw |
|
Net weight |
755kg |
|
Gross weight(with wooden package) |
865kg |
|
Overall dimensions |
3250×3500×870mm |
