| Item | Unit | HPS1500 |
|---|---|---|
| Runching Capacity | Ton | 30 |
| X Traverse Length | mm | 1525±10 |
| Y Traverse Length | mm | 1525±10 |
| Max sheet Size | mm | 1525x3050 |
| Max sheet Thickness | mm | 6.35 |
| Max Mass of Material | kg | 110 |
| X Axis Traverse Speed | M/min. | 80 |
| Y Axis Traverse Speed | M/min. | 70 |
| Max Traverse Speed | M/min. | 105 |
| punching Speed at 25mm pitch | hits/min. | 280 |
| Nibbling Speed (stroke length 4mm, pitch 1mm) | hits/min. | 600 |
| Tool Type | Thick turret | |
| Max Punching Diameter | mm | 114.3 |
| Number of Tool Stations | 40 | |
| Numer of Auto Index Stations | pcs(type) | 2D |
| Turret Rotating Speed | rpm | 40 |
| Auto Index Rotating Speed | rpm | 50 |
| Ram Stroke Distance | mm | 0-31 |
| Working Table | Ball+Brush | |
| Number of Sheet Clamps | pcs | 2 |
| Power Supply | KVA | 30 |
| Air Supply | NL/min | 250 |
| Oil Tank Volume | Litre | 250 |
| Air Pressure | bar | 5 |
| Size of Control Cabinet | mm | 1200 × 600 × 1900 |
| CNC Controller | FANUC | |
| Number of Controllable Axis | Axis | 4 |
| RAM Memory | KB | 512 |
| Serial Interface | RS232 | |
| Punching Precision | mm | ±0.1 |
| Machine Dimension (L × W × H) | mm | 5190*3250*2550 |
| Net Weight (approx.) | kgf | 14000 |
