| CAPACITY | |
| Table travel (X axis) | 1400mm |
| Head travel (Y axis) | 1200mm |
| Table travel (Z axis) | 1100mm |
| Spindle center to table top | 0-1200mm |
| Spindle end to table center | 255-1355mm |
| TABLE | |
| Table size overall | 1100 x 800mm |
| T slot (width x no.x pitch) | 20 x 7 x 100mm |
| Table load capacity max. | 1400kg |
| MAIN SPINDLE | |
| Spindle nose | ISO R297 NO.50 |
| Spindle speed (60Hz) 12steps | 45-1500rpm |
| FEED | |
| X,Y,Z rapid traverse (60Hz) | 2880mm/min |
| X,Y,Z auto feed (60Hz) | 28-875mm/min |
| Z axis boring feeds (12steps) | 0.028-0.875mm/rev |
| MOTORS | |
| Spindle motor | AC7.5kW-4P |
| Feed motor | AC1.5KW-4P |
| Lube pump for headstock | AC0.2KW-4P |
| Lube pump for sideways | AC3.5W-2P |
| Coolant pump | AC0.12KW-2P |
| Hydraulic pump for axis clamper | AC1.5KW-4P |
| GENERAL INFORMATION | |
| Floor area | 3310 x 3600mm |
| Net weight (Approx.) | 8400kgs |
