| CAPACITY | ||
| X axis (Table longitudinal) | 1600mm | |
| Y axis (Spindle vertical) | 1000mm | |
| Z axis (Table cross) | 1250mm | |
| W axis (Spindle axial) | 400mm | |
| Spindle center to table top | 0-1000mm | |
| Spindle end to table center | 362-1612mm | |
| TABLE | ||
| Work space | 1000x800mm | |
| Table index | 1 degree/division | |
| T-Slot (width *no. *pitch) | 22x7x100mm | |
| Table load capacity | 2500kgs | |
| SPINDLE HEAD | ||
| Spindle nose | ISO R297 No.50 | |
| Spindle diameter | 110mm | |
| Spindle Speed | 20-1000 rpm | |
| FEED / RAPID | ||
| X.Y.Z rapid | 2800mm/min | |
| W rapid | 1200 mm/min | |
| X,Y,Z feed | 3~950 mm/min | |
| W feed | 3~400 mm/min | |
| Change of feeds | Infinitely variable | |
| MOTOTS | ||
| Spindle motor | AC20HP | |
| Feed motor for X,Y,Z axis (Servo) | 2.9kW | |
| Feed motor for W axis (Servo) | 1.3kW | |
| Lube pump for headstock | AC0.2kW-4P | |
| Lube pump for slideway | AC3.5W-2P | |
| Coolant pump | AC1/6HP (0.12kW-2P) | |
| Hydraulic pump for axis clamp | AC2HP (1.5kW-4P) | |
| MACHINE SIZE | ||
| Floor area | 3874x4317mm | |
| Machine weight (Approx.) | 12000kgs | |
