| ITEM | 110L |
| CAPACITY | |
| X axis (Table longitudinal) | 1800mm |
| Y axis (Spindle vertical) | 1400mm |
| Z axis (Table cross) | 1400mm |
| W axis (Spindle axial) | 550mm |
| Spindle center to table top | 0-1400mm |
| Spindle end to table center | 577-1977mm |
| TABLE | |
| Work space | 1200x1400mm |
| Table index | 1 degree/division |
| T-Slot (width *no. *pitch) | 22Hx9x120mm |
| Table load capacity | 5000kgs |
| SPINDLE HEAD | |
| Spindle nose | ISO R297 No.50 |
| Spindle diameter | 110mm |
| Spindle Speed | 20-1500 rpm |
| FEED / RAPID | |
| X.Y.Z rapid | 2800mm/min |
| W rapid | 1200 mm/min |
| X,Y,Z feed | 3~950 mm/min |
| W feed | 3~400 mm/min |
| Change of feeds | Infinitely variable |
| MOTOTS | |
| Spindle motor | AC20HP |
| Feed motor for X,Y,Z axis (Servo) | 2.9kW |
| Feed motor for W axis (Servo) | 1.3kW |
|
|
|
|
